    Acrylic Crytal Robotic Welding System , Robotic Laser Cutting Welding Equipment

    Ask Lasest Price
    Brand Name : CMC
    Certification : ISO,CE
    Price : according to the machine requirement
    Payment Terms : Down payment 30% T/T, 70% T/T before shipping
    Supply Ability : According requirement
    Delivery Time : according to the machine requirment
    • Product Details
    • Company Profile

    Acrylic Crytal Robotic Welding System , Robotic Laser Cutting Welding Equipment

    CNC 0.1mm - 1.6mm CE Robot welding cutting machine for Acrylic Crytal

    Specifications

    welding robot
    1. Gear Rack Moving;
    2. 55m/min;
    3. 3000*1500mm;

    Advantages


    It adopts the most advanced Fiber Laser Source, Gear-rack Transmission from Atlanta Germany, Reducer from

    Stowe Bell Germany, Servo Motor from Yaskawa Japan, PA8000 Top-level CNC Control System, Linear Guide

    Rail from HIWIN Taiwan.


    Equipment Introduction


    SFC system is a cost-effective investment including Fiber Laser Source, Water Cooling System, Automatic

    Laser Head, Cutting Flatbed, Control System, Exhaust System etc.



    Structure


    Overall fixed workpiece&Gantry-type structure, 3-axis movement controlling system, X&Y axis achieves flat

    surface movement, Z axis tracks material surface with floating up&down movement.



    Clean Robots

    • Semiconductor and Electronics
    • HIGH-PERFORMANCE SPECIALIZED HANDLING ROBOTS
    • Kawasaki offers a full line of industry-leading semiconductor and electronics handling robots. These robots are built for use in cleanroom applications, including ISO Class 1. Speed, accuracy, and reach make these robots ideal for handling delicate semiconductor wafers, LCD panels, organic EL, and solar panels.
    • Clean Robots:
    • Click on a series below to learn more. Note: images not shown to scale.

    NS Series

    • Classic Cylindrical Design
    • RTZ motion actuation
    • 300 mm wafers
    • NS Series

    NX Series

    • Next-Generation NS Design
    • Independent axis drive
    • 300 mm wafers
    • NX Series

    NV Series

    • Vacuum Environment Arm
    • Compact and lightweight
    • Minimizes vibration
    • NV Series

    TT Series

    • Telescopic Base Design
    • Large vertical reach
    • Long reach NT Manipulator
    • TT Series

    TX Series

    • Telescopic Base Design
    • Large vertical reach
    • Medium reach NX manipulator
    • TX Series

    WIDE WORKING RANGE

    The next-generation designs of clean robots feature an independent drive on all axes, which significantly increases the usable work area with minimal dead-space and greater flexibility. The TT and TX series are designed with telescopic bases for applications requiring large vertical reach.


    HANDLING OPTIONS AVAILABLE


    A wide variety of handling options are available across the clean robot series. Both 300 mm and next-generation 450 mm wafer handling robots are available, along with dual-gripping technology that allows a single robot base to handle two wafers. Models are also available with an additional axis for handling wafers at both horizontal and vertical angles.


    CLEANROOM SPECIFICATION


    Strict design and assembly standards allow this series of arms to conform with a range of ISO cleanroom standards, as well as adhering to the SEMI F47 and SEMI S2 standards for voltage and safety requirements.

    PROGRAMMING FLEXIBILITY

    Clean series robot controllers offer superior programming flexibility with manual, semi-automatic, and full-automatic teaching methods. Ethernet communication port as a standard enables a high level of communication with various equipment in a facility.
